Extend your paging coverage with the WPRP-HP High-Power Wireless Paging Repeater. Designed for facilities where the main transmitter’s signal is weak or obstructed, this wireless repeater boosts RF signal range and reliability for voice, data, and time-sync communications. The WPRP-HP main features are:
Supports both digital and analog paging formats
Operates in the UHF frequency band for long-range transmission
Highly sensitive radio receiver with narrow band support
Handles one-way or two-way paging, time sync, and data messaging
Improves coverage in remote or shielded facility zones
The WPRP-HP Wireless Paging Repeater is a high-power RF repeater that boosts the reach of your Visiplex paging system. Ideal for large campuses, multi-building facilities, and shielded indoor areas, the WPRP-HP is designed to retransmit weak or blocked signals, extending your system’s effective range.
This paging repeater supports digital and analog paging formats and can operate across two different UHF frequencies, enabling reliable one-way voice announcements, data messaging, and synchronized clock signals. Whether used in warehouses, healthcare campuses, manufacturing plants, or schools, the WPRP-HP ensures consistent and dependable signal coverage throughout your facility.
Weight
12 lbs
Dimensions
18 × 18 × 6 in
Product Dimensions
14" x 11.5" x 3.5" (W x D x H)
Product Weight
9.5 lbs.
Power
90-240V AC 50/60Hz
Color
Black
Operating Temperature
10° – 140°F
Output Power
36 dBm
RF Connector
Type N Jack (Complementary BNC Female to N Male Adapter Provided if Required)
Receiver Sensitivity
<110dBm
Selectivity
50dB
Input / Output Impedance
50 Ohm
Modulation
FM
Frequency Range
UHF (410 – 470 MHz)
Channel Spacing
12.5 KHz – Narrow Band
Stability
± 2.5 ppm
Data Format
Digital 512-2400 BPS Analog – 100Hz – 3.6KHz
Enclosure
Durable Metal Case with LED power, PTT, and Data Indicators
